    2.6x3x0.5 tact switch EVPAFB70 Low Profile SMT Tactile Switch

    2.6x3x0.5 tact switch EVPAFB70 Low Profile SMT Tactile Switch Featured Image
    • 2.6x3x0.5 tact switch EVPAFB70 Low Profile SMT Tactile Switch

    Short Description:

    Product description
    Item name: 2.6x3x0.65 tact switch
    Model No.: TS263065A
    Rating: 50mA. 12VDC
    Dielectric strength: 250VAC for 1 min
    Contact resistance: 50mΩ max
    Operating temperature: -30℃~+85℃
    Lifetime: 500,000 cycles min
    Operating force: 180gf;250gf
    Travel: 0.15±0.05mm
    Usage:
    - For operating various devices such as audio devices,video recorders,communication devices,cameras and automotive sets that require low-profile and lightweight design.
    - Mobile phone PCBA circuit board.
