2 pin usb type c jack connector female socket vertical plug fast mobile charging port support customization
Short Description:
product name TYPE-C 2PIN connector model number TYPE-C 2PIN H6.8 molding LCP UL94 V-0 Rated voltage 5V Withstand voltage 100V AC Insulation resistance 100 MΩ Insertion force 0.5-2.0kgf Pullout force 0.61-2.04KG Number of insertions 5000 cycles Operating temperature -20℃~+85℃
