Competitive Price for Type C Charging Connector - HOT SALE 180 degree 10.0 USB connector – Shouhan Detail:

ENTERPRISE ADVANTAGE:
Focus on professional: Shouhan Technology has more than 10 years of industry sales experience, in-depth understanding of customer needs and characteristics, and has a professional customer service team, to provide effective service for customer service.
Reasonable price: Shouhan technology is a factory trading company, there is no middleman to earn the price difference, to the majority of customers to save a lot of costs.
Product assurance service: all products of the company enjoy quality assurance service, we promise to receive the goods within 90 days of quality problems can be returned.
On the day of delivery the next day: the company’s conventional products can be fast delivery, the Pearl River Delta region in the morning afternoon, afternoon morning, to solve the customer to goods difficult to urgent trouble.
Intimate service:
Pre-sales: recommend suitable products according to customers’ needs
In sale: fast quotation, give reasonable suggestions to customers
After sales: senior technical team on-site guidance solutions, to provide professional solutions
Mission:Let switches and sockets enter thousands of households to promote the development of the industry;
Sense of worth:Service srpremacy,unity and struggle,Respect and Love Your Job,firm belief and positive contributions;
Vision:Happiness index first class enterprise,become industry benchmark;
Gratitude:Willing to share and to be grateful;
Sincerity:Words must be done;
Innovate:Do not indulge in comfort,dare to break through,take the initiative to find solutions,subversion mode;
Win-win:
Employee:Make the best of yourself in SHOUHAN
Customers:customers who choose SHOUHAN will not be disappointed.

Specifications:
Electrical:
1.Current Rating: 1.5A/contact terminal
2.Voltage Rating: 30V DC
3.Contact Resistance: 30 milliohms MAX
4.Dielectnic Withstanding Voltage: 500 V AC(50Hz)/min
5.Insulation Resistance: 1000MEGA ohms MIN
Mechanical:
1.Connector Mate and Unmate Force
CONNECTION FORCE: 35N
DISCONNECTION FORCE: 10N
2.TERMINAL STRENGTH: 1.0kgf/cm for 1 min (MIN)
Matorial:
1.Rubber core: PBT White,
2.Contact: Copper Alloy C2680
3.Shell: Copper Alloy C2680/SPCC
Finish:
1.Contact:Contact area gold plated 1U”
Welding area bright tin plating 100-200U”
2.Shell: Full area nickel plating 50-80U”

STANDARD ATMOSPHEIC CONDITIONS:UNLESS OTHERWISE SPECIFIED THE STANDARD RANGE OF ATMOSPHERIC CONDITIONS FOR MAKING MEASUREMENTS AND TESTS ARE AS FOLLOWS:
(1) BETWEEN BODY AND CONDUCTOR: 5ºC TO 35℃
(2) BETWEEN CONDUCTORS NOT TO BE CONTACT:45% TO 85%
(3) PRESSURE:86Kpa TO 106Kpa
SOLDERABILITY TEST:THE TOP OF THE TERMINALS SHALL BE DIPPED 1mm IN THE SOLDER BATH OF 250±5℃ FOR 5±0.5 SECONDS
RESISTANCE TO SOLDERING HEAT TEST:
REFLOW SOLDERING CONDITIONS:
PREHEAT:TEMPERATURE ON THE COPPER FOIL SURFACE SHOULD REACH 180 .120 ℃ S AFTER THE P.C.B ENTERED INTO THE SOLDERING EQUIPMENT.
TALLEST TEMPERATURE:TEMPERATURE ON THE COPPER FOIL SURFACE SHOULD REACH THE PEAK TEMPERATURE OF 260±5 WITH IN 20 SECONDS. ℃
SOLDERING IRON METHOD: BIT TEMPERATURE 330±5℃ APPLICATION TIME OF SOLDERING IRON3±0.5 SEC HOWEVER EXCESSIVE PRESSURE SHALL NOT BE APPLIED TO THE TERMINAL

详情页1 详情页2 详情页3




Product detail pictures:

Competitive Price for Type C Charging Connector - HOT SALE 180 degree 10.0 USB connector – Shouhan detail pictures

Competitive Price for Type C Charging Connector - HOT SALE 180 degree 10.0 USB connector – Shouhan detail pictures

Competitive Price for Type C Charging Connector - HOT SALE 180 degree 10.0 USB connector – Shouhan detail pictures
