    DC-044B CORE PIN = 2.0 / 2.35 / 2.5 MM notebook socket DC044B 5PIN seat suitable for the notebook DC044B

    DC-044B CORE PIN = 2.0 / 2.35 / 2.5 MM notebook socket DC044B 5PIN seat suitable for the notebook DC044B Featured Image
    • DC-044B CORE PIN = 2.0 / 2.35 / 2.5 MM notebook socket DC044B 5PIN seat suitable for the notebook DC044B

    Short Description:

    DC-044B CORE PIN = 2.0 / 2.35 / 2.5 MM notebook socket DC044B 5PIN seat suitable for the notebook DC044B

    Product info
    Item name: DC socket
    Model No.: DC031
    Current: 0.5A
    Voltage: 30V
    Operating force: 250gf
    Lifetime: 5,000 cycles
    Operating temp.range: -20~+50℃
