evpaebb2m/EVQP42B3M 12V 0.5A 3*6 tact switch SMD/SMT

Short Description:

Certification:ROHS

Whether the smart:NO

Place of Origin:Guangdong, China

Brand Name:SHOUHAN

Model Number:TS36CB EVQP42B3M

Protection Level:IP40

Max. Current:50mA

Max. Voltage:12V

LED:NO

Product Name:3*6 tact switch tactile switch SMD/SMT heavy plate side press

Model:TS36CB EVQP42B3M

Operating temperature:-20℃-70℃

Storage temperature:-30℃-80℃

Contact Resistance:≤100mΩ

Insulation Resistance:≥100mΩ

Operating Force:250gf±50gf

Full travel:0.2±0.05mm

Send email to us

Product Detail

Product Tags

The EVPAEBB2M and EVQP42B3M Tactile Switches are high-quality electrical components that offer exceptional performance. With a voltage rating of 12V and a current rating of 0.5A, these switches are versatile and can be used in a wide range of electronic devices. Whether you need them for consumer electronics, automotive applications, or even industrial machinery, these switches have got you covered.

One of the key features of these switches is their compact SMD/SMT form factor. This design allows for easy installation on printed circuit boards and saves valuable board space. The switches feature a 3×6 size, making them ideal for applications with limited room.

Designed with durability in mind, the EVPAEBB2M and EVQP42B3M Tactile Switches are built to last. The heavy plate side press feature ensures a robust and reliable operation, with a tactile feedback that confirms successful input. This is crucial in applications where user interaction is essential, such as keyboards, remote controls, or any device that requires tactile response.
