Factory best selling Micro Usb Female Water Proof Connector Pcb - HOT SALE RJ45 with LED light manufacture PCB modular jack with light computer component 8 pin rj45 female connector – Shouhan Detail:

NOTES:
MATERIAL:
1.HOUSING MATERIAL:GLASS FILLED POLYESTER UL94V-0
2.CONTACT MATERIAL:PHOSPHOR BRONZE Φ0.46mm
3.PLATING:GOLD PLATING OVER NICKEL
4.SHIELD:0.2mm THICKNESS COPPER ALLOY WITH NICKEL PLATED
5.LED:OPTION
ELECTRICAL:
1.VOLTAGE RATING :125VAC RMS
2.CURRENT RATING:1.5 AMP
3.CONTACT RESISTANCE:30 MILLIOHMS MAX
4.INSULATION RESISTANCE:500 MEGOHMS MIN @ 500V DC
5.DIELECTRIC WITHSTANDING RESISTANCE:1000V AC RMS 50Hz 1MIN
MECHANICAL:
1.DURRABILITY:750 CYCLES MIN
2.PCB RETENTION PRE-SOLDER:1 LB MIN
ENVIRONMENTAL:
1.STORAGE:-40℃~+85℃
2.OPERATION:-40℃~+70℃

Part No. Information:
1124.11121.60x300

“X” FINISH:
1=Gold 1u”
2=Gold 3u”
3=Gold 6u”
4=Gold 15u”
5=Gold 30u”
6=Gold 50u”


英文详情页产品实拍版块模板主图6


Product detail pictures:

Factory best selling Micro Usb Female Water Proof Connector Pcb - HOT SALE RJ45 with LED light manufacture PCB modular jack with light computer component 8 pin rj45 female connector – Shouhan detail pictures

Factory best selling Micro Usb Female Water Proof Connector Pcb - HOT SALE RJ45 with LED light manufacture PCB modular jack with light computer component 8 pin rj45 female connector – Shouhan detail pictures

Factory best selling Micro Usb Female Water Proof Connector Pcb - HOT SALE RJ45 with LED light manufacture PCB modular jack with light computer component 8 pin rj45 female connector – Shouhan detail pictures
