High current 4 pin usb 3.0 type a female connector usb connector socket 30V 1.5A

High current 4 pin usb 3.0 type a female connector usb connector socket 30V 1.5A Featured Image

Short Description:

product name	usb connector
Product number	10.0 Full sticker crimping 6.3
PIN number	4 pin
Rated voltage	30V
Rated current	1.5A
Insulation resistance	1000MΩ
Contact Resisitance	30MΩ MAX
Withstand voltage	500V AC
Insertion force	3.57Kgf
extraction force	1.02Kgf
life	5000 (times)
Operating temperature	-25℃~+85℃
