Hot New Products Micro Limit Switch Function - HOT SALE High quality 0.02A 12V Vibration Switch SW-18010P – Shouhan Detail:

Quick Details

Certification: Rohs
Whether the smart: No
Place of Origin: Guangdong, China
Brand Name: OEM/SHOUHAN
Model Number: SW-18010P
Max. Current: 20mA
Max. Voltage: 12V
Item name: 0.02A 12V vibration switch SW-18010P shaking switch reed switch
Heat resistance: 100℃
Rated load: DC12V 20mA
Work cycle: 200,000 cycles
Conductive time: 0.2ms

1. The switch at rest for open state (OFF) when the external force contact surface reached the appropriate vibration force when the conductive pin will produce instant conduction state (ON), so that the electrical characteristics change, and when the external force disappear, the electrical characteristics restore open state (OFF);

2. No direction, any Angle can trigger the work;

3. This model is waterproof and sealed;

4. This switch is suitable for small current circuit trigger;

5. Switch pin welding temperature: hand welding 260℃±10℃;

6. The switch has been treated with oxidation resistance and can be used for more than one year.

 Electrical characteristics
 1  voltage  Less than 12 V
 2  current  Less than 20 mA
 3  Conduction time  About 2 ms
 4  Closed circuit resistance  <10ohm
 5  Open circuit resistance  >10M ohm



Mechanical properties
 1  temperature resistance  100℃
 2  Terminal pull  500gf for 1 minute
 3  humidity  95% RH 40℃, 96 hours
 4  Operating life  Over 100,000 cycles



Material list
1 Plastic pipe Blue ABS
2 needle Brass wire, gold plated
3 spring Brass, gold plated
4 Heat shrinkable tube PET heat shrinkable tube black
5 The sealing colloid temperature resistance of nylon

Welding characteristics:

Solder: tin content of 100%

Welding humidity: 260℃±10℃

Welding time: 2-2.5 seconds

Do not use strong acid, alkaline flux

Packing:

1000PCS/bag (PVC plastic bag)



国际站英文详情页产品实拍

耐温


Product detail pictures:

Hot New Products Micro Limit Switch Function - HOT SALE High quality 0.02A 12V Vibration Switch SW-18010P – Shouhan detail pictures

Hot New Products Micro Limit Switch Function - HOT SALE High quality 0.02A 12V Vibration Switch SW-18010P – Shouhan detail pictures

Hot New Products Micro Limit Switch Function - HOT SALE High quality 0.02A 12V Vibration Switch SW-18010P – Shouhan detail pictures
