    multiple models 4pin patch usb type c female connector socket support customization

    multiple models 4pin patch usb type c female connector socket support customization Featured Image
    • multiple models 4pin patch usb type c female connector socket support customization
    • multiple models 4pin patch usb type c female connector socket support customization
    • multiple models 4pin patch usb type c female connector socket support customization
    • multiple models 4pin patch usb type c female connector socket support customization

    Short Description:

    product name type c 4 pin connector
    model number type c 4 pin
    Contacts material Copper Alloy
    front shell Stainless steel
    Insertion force 0.5-2.0kgf
    removal force 0.8-2.0kgf
    durability 5000 cycles
    current rating 3.0A
    voltage rating 5.0A
    Insulation resistance 100MΩ MIN
    Operating  Temperature -25℃ ~ +85℃

    Product Detail

    Product Tags

    Hbe8c4eed5e2249ba8d40f633dfd1a5e0j.jpg_720x720q50.webp H984f98023cc542e68a04d7c7514545e4c
