on-off push button switch ESB30B134/ESB30B304/ESB30B305 emergency self-latching switch

Short Description:

Product‘s name Operating Mode Operating force Lock travel Full travel Swithching Mode Mouting Type Terminal Type
ESB30B102 Self-lock 2.0N±1.0N 2.5MM 3.0MM Non-shorting Dip type Formed terminal
ESB30B103 Self-lock 3.5N±1.5N 2.5MM 3.0MM Non-shorting Dip type Straight terminal
ESB30B132 Self-lock 2.0N±1.0N 2.5MM 3.0MM Non-shorting Dip type Straight terminal
ESB30B133 Self-lock 3.5N±1.5N 2.5MM 3.0MM Non-shorting Dip type Formed terminal
ESB30B304 Non-Lock 2.0N±1.0N 2.5MM 3.0MM Non-shorting Dip type Straight terminal
ESB30B305 Non-Lock 2.0N±1.0N 2.5MM 3.0MM Non-shorting Dip type Formed terminal
ESB30B332 Non-Lock 3.5N±1.5N 2.5MM 3.0MM Non-shorting Dip type Straight terminal
ESB30B333 Non-Lock 3.5N±1.5N 2.5MM 3.0MM Non-shorting Dip type Formed terminal
