SK-12D07VG3 3 Pin metal Slide Switch on off switch DC 50V 500mA customizable

SK-12D07VG3 3 Pin metal Slide Switch on off switch DC 50V 500mA customizable Featured Image

Short Description:

product name	slide switch
Product number	SK-12D07VG3
Rated value	DC 50V 500mA
Operating temperature range	-10℃~+50℃
contact resistance	≤50MΩ
Insulation resistance	≥100M Ω
Action force	200±50gf
Action stroke	2mm±0.2mm
life	5000 (times)
switch type	single level double

Send email to us

Product Detail

Product Tags

Previous: single and two-color lights blue red push button tact tactile switch with light led

Next: one-stop purchase multiple models TS665CJ 6*6mm 4pin tactile tact push button switch support customization

0.5 A slide switch

2 positions slide switch

3 pin slide switch

on off slide switch
