Top Quality Dc Plug Female Socket - EVPAA002K 3x4x2mm smd micro tact switch TS342A2P tactile switch – Shouhan Detail:

SMD SMT Top Actuated tact switch

12V 50mA tact switch

Sensitive small and thin tact switch



Product Parameters

Max. Current: 50mA

Max. Voltage: DC12V
Contact Resistance: ≤50mΩ
Insulation Resistance: ≥100MΩ

Operation Stroke: 0.13±0.05mm

Life: 10000 cycles Min
Compressive strength: AC250V 50Hz/1 min

Height: 1.7±0.1mm

Actuator: top



The role of the ground pin

The longer of the three legs is grounded and can be called the ground pin, and the other two shorter legs are used to connect household appliances to the circuit, so they can be called conductive pins. If the metal shell of the household appliance is charged due to the damage of the insulator or other reasons, the ground pin will form a ground short-circuit current, so that the metal shell of the household appliance is grounded and discharged to the ground, so that people will not be electric shocked and play a role of safety protection.



The difference between tact switch and push button switch

1) Tact switch is a kind of click switch, that is to say, press to turn on and release to turn off. Simply put, it is to tap the switch that turns on instantly.

2) The push button switch refers to the  switch that is pressed to turn on. In fact, the tact switch also adressed as push button switch. Push button switch usually means that a switch with a larger stroke can be self-locking and non-locking, highlighting the force of a press. The tact switch means short stroke, short contact, and light touch.











Product detail pictures:

Top Quality Dc Plug Female Socket - EVPAA002K 3x4x2mm smd micro tact switch TS342A2P tactile switch – Shouhan detail pictures
