HOT SALE high current side insert female jack double row 14pin side plug usb3.1 type-c 14pin connector

Short Description:

Product description

Item name: type c 14pin USB connector

Rating: DC 20V 5A

Insulation resistance: ≥1000mΩ min. 500V DC

Dielectric strength: 250V AC for 1 min

Contact resistance: ≤50mΩ

Insertion force: ≤5-20N

Extraction force: ≥8-20N

Usage:

-Mainly used in high end industries,such as digital camera interface products,computer accessories,electronic toys,mobile phone charging interface and other products need to charge.

Send email to us

Product Detail

Product Tags

Quick Details

Model Number:: Type C 14pin side plug

Type:: USB Type C

Place of Origin:: China

Item name:: usb3.1 type-c 14pin connector

Current Rating:: 5A

Voltage Rating:: 20V DC

Operation Temperature:: -30℃ ~ +85℃

Operating:: 10000 cycles

Usage:

Use for pcb board

Product Name	High quality high current side insert female jack double row 14pin side plug usb3.1 type-c 14pin connector
Life	≥10,000 cycles
Insulation resistance	100mΩ Min
Contact resistance	40mΩ Max
Temperature	-30℃ to +85℃
Rated Voltage	20V Max
Rated current	5A Max
